LOTO Procedures

Machines can be a great advantage to employee productivity, allowing one employee to complete as much work as many employees could without it.  For all their benefits, though, machines cannot differentiate between humans and manufacturing materials and can severely injure people.  Machine operators must be protected by machine guards that limit worker exposure and provide sufficient protection from hazards during typical operation of the machine.  Machine guarding doesn’t protect workers who maintain and service the machines though, since their work often requires them to remove the guards and bypass the safety features that protect operators. This is where LOTO plays an important role and the Lockout Tagout procedures is a must for every organisation practising LOTO.

Lockout/Tagout, or Control of Hazardous Energy (29 CFR 1910.147), is an OSHA regulation implemented to protect maintenance and service workers in the performance of their duties.  It specifically addresses hazards that could injure employees from the unexpected energization or start up of machines or equipment, or when stored energy could be released, while servicing or maintaining equipment.  Employees are protected by following the procedures to shut down the machine and ensure that it cannot activate while they are working on it.

Who must have a Lockout/Tagout (LOTO) Program?

All companies whose employees service or maintain equipment with potentially Hazardous Energy sources must have an OSHA-compliant Lockout/Tagout program.

What is a Lockout / Tagout (LOTO) Program?

A Lockout/Tagout program must include the following:

• Plant- or company-wide safety policies.
• Machine-specific lockout procedures.
• Lock, key and tag control
• Program review and certification.
• Outside contractor rules and regulations.

Training for employees includes classroom and hands-on instruction. Authorized employees must demonstrate their proficiency in startup and shutdown procedures. A copy of OSHA 29 CFR1910.147 should be readily available for reference.

LOTO Procedures

The specific actions for applying LOTO will differ from equipment to equipment, and from organisation to organisation.  The general LOTO procedures should follow a basic 8 step process.

Step 1: Detailed procedures for equipment
Start by making sure you’ve identified the equipment correctly and accurately, including its specific location. Next, determine the correct procedure for shutting down and restarting the equipment. Detail that procedure, step by step, in writing. Consider all of the energy sources that may be connected to the equipment. Be very specific, because ambiguous language could lead to an incorrect or even dangerous action.

Step 2: Notify affected employees
When maintenance is going to be performed, all of the employees that may be affected should be notified. Let them know the timing of the work, and how long the equipment may be unavailable. If the unavailability of the equipment requires a change in work processes, be sure they are familiar with the steps to be taken.

Step 3: Shut down equipment properly
Explain the shutdown process in detail. It’s not enough to say something like “disconnect the machine.” To ensure everyone’s safety and reduce the potential for damage, the shutdown instructions should be detailed. Spell out the exact actions to be taken and the correct sequence for performing those actions.

Step 4: Disconnect all primary energy sources
Although this may seem fairly self-explanatory, once again, it’s important to be very detailed. Whether the primary energy sources include electricity, steam, water, gas, compressed air, or others, don’t assume that the person performing maintenance will know the correct procedure to follow. Again, explain exactly what needs to be done.

Step 5: Address all secondary sources
While disconnecting the primary energy sources may remove much of the potential danger, it’s possible that there sources of residual energy, such as trapped heat in a thermal system, fumes that may need to be vented, or even tension in a spring assembly. Identify the process that will relieve any remaining pressure or other energy. Also consider other hazards, such as moving equipment that must be secured before work begins.

Step 6: Verify the lockout
Once you’ve disconnected all primary and secondary sources of energy, attempt to start the equipment to verify that the lockout has been successful. Before you try to start it, verify that nobody is in a position where they could be hurt. Assuming that the procedures have been successful, return all switches and other equipment back to their “off” positions so the machine won’t start unexpectedly when the energy sources are reconnected. Once you’ve verified the lockout, attach a lockout or tagout device to the equipment to ensure that it cannot be started without removing the device.

Step 7: Keep it in force during shift changes
The equipment must remain in lockout/tagout condition across shift changes, so that workers arriving at the site are aware that the equipment is out of service. If individual locks or tags are used, the individual responsible for designating the lockout/tagout and the individual responsible for it during the next shift must both be present as the locks or tags are switched.

Step 8: Bring the equipment back on line
When the work is done and all tools and other materials have been removed, the machine can be brought back into operation. Here again, the procedure should spell out the exact steps that are involved, along with the correct sequence. For example, you may need to open a particular machine’s discharge valves before you open the inlet, so any unexpected water or steam remaining in the lines has a place to go.

Always Keep procedures up-to-date
Equipment and operating procedures tend to change over time, and your lockout/tagout program needs to reflect those changes. Sometimes, the changes may be so minor that only the people working directly with the equipment are aware of them. That’s why it’s a good idea to review all your lockout/tagout procedures regularly to verify that they’re still accurate. A company with just a small number of machines may be able to check all of them every year, while a larger organization may need to study a certain number or a random sample every year. Another benefit of regular review is that it gives you an opportunity to deploy newer and better ideas or more accurate descriptions.
